Description
- Electrical height adjustment
- Electrical backrest adjustment
- Electrical thigh rest adjustment
- Electrical Trendelenburg & Reverse Trendelenburg adjustment
- Mechanical footrest adjustment
- Wire mesh mattress platform
- Wooden side rails with up & down movements
- IV pole, height adjustable
- 4 castors, 2 with brake
- Electrostatic powder coated metal frame – RAL 1001
- Handset control
- Wooden head & foot boards
TECHNICAL FEATURES
- External dimensions: 2120 x 1060 mm
- Mattress platform: 1900 x 900 mm
- Height adjustment: 440 – 740 mm
- Backrest max. angle: 70°
- Footrest max. angle: 40°
- Trendelenburg/Rev. Trendelenburg: +12o / – 12o
- Side rails height: 380mm
- Head-Foot boards height: 540 mm
- Under bed clearance: 160 mm
- Castors diameter: 125 mm
- Safety working load: 150 kg
- Max. loading capacity: 300 Kg
OPTIONAL FEATURES
- Weight scale system
- Central lock castors
